Description

PRODUCT FEATURES

1. A wide range of product categories

Hiconics with the fourth generation VFD can provide different load types, different current scope of

The power cells, which can meet most of the industrial and mining enterprises control requirements.
Classified by Power: 315kw~20000kw
Classified by Cabinet: compact cabinet, separate cabinet, water cooled cabinet, outdoors cabinet, flameproof cabinet
Classified by voltage: 3.3kV, 4.16kV, 6kV, 6.6kV, 10kV, 11kV (2.3kV,13.8kV on customer,s request)
Classified by cooling mode: air forced cooling, water cooling Classified by Motor: synchronous motor, asynchronous motor Classified by Performance: standard MV Drive, AFE MV Drive

2. Main controller chips

The main controller chip uses TI’s TMS320F28335 digital signal processor, the device has
the advantages of high precision, low power consumption, high performance, high peripheral integration, data and program storage capacity, and A/D conversion more accurate and fast. TMS320F28335 has 150MHz high-speed processing capability, 32-bit floating-point processing unit, 6 DMA channels, support ADC, McBSP and EMIF. With up to 18 PWM outputs, six of them are TI’s more accurate PWM outputs (HRPWM) and 12-bit 16-channel ADCs. Thanks to its floating-point calculation unit, users can quickly write control algorithms without having to spend too much time and effort on decimal operations, with an average performance improvement of 50% over the previous generation DSPs. At the same time, the application of better control algorithm, so that the waveform of the inverter running at low-frequency current and output harmonics have a significant increase.
